Color Handheld Ultrasound RK-4CPLT

.Scan mode: Electronic Array, Electronic Convex & Linear array scanning

.Frequency: Convex/Phasedarray 3.2/5.0MHz or 3.2/4.OMHz,Linear probe 7.5/10MHz or 10/13.2MHz, Transvaginal 6.6/8.0MHz

.Scanning Depth: Convex 90/160/220/305mm, Linear 20/40/60/100mm,Transvaginal 20/40/60/100, adjustable

 .Field of view: Convex R60, Phasedarray R80, Transvaginal R13, Linear L40

 .Image Adjustment: gain, focus, reverse pulse harmonics, noise reduction

 .Puncture Auxiliary Function: In-Plane puncture quide, Out-Plane puncture guide, automatic vascular measurement function

.Measure: Thyroid, small organs, pediatrics, blood vessels, carotd arter, breast,musculoskeletal, blood flow, nerves, abdomen.gynecology, obstetrics, heart,urinary system, kidneys, lungs

.Power: by built-in lithium battery, 2800mAh, wireless charging can extend the working time indefinitely

. Playback : manual and automatic, playback frames to be 100/200/500/1000

Linear array COLOR mode

PRF > 4 groups

Wall filter 0-15

Color gain 0 - 10

Deflection angle -12/-7/0/7/12 degrees

Convex Array COLOR Mode

Deflection Angle: Not Available

PRF:> 4 groups

Wall Filter:0 - 15

Color Gain: 0- 10

Convex array PW mode

Sampling volume: 1,2, 5 mm

Baseline: 0 - 800 cm/s

PRF:> 4 groups

Correction angle: -85 to 85 degrees

Cardiac COLOR mode

Deflection angle: Not available

PRF 4 groups

Wall filter: 0- 15

Color gain:0-100

Cardiac PW mode

Sampling volume: 1, 2, 5 mm

Baseline:0 - 600 cm/s

PRF 2 4 groups, Note: For USB phased

array probe,

PRF is 2 -20K > 8 groups

Correction angle: -85 - 85 degrees

Linear array PW mode

Sampling volume: 1,2, 5 mm

Baseline:0- 500 cm/s

PRF >4 groups, Color gain: 0- 100

Correction angle: -85 - 85 degrees
